Lifestyle 8 series II
The Lifestyle 8 series II system includes: one
CD5V2 (single disc CD player) music center, one RC-9 remote control,
one AM8P series II digital bass module and five single cube satellite speakers.
NOTE: The CD5V2 music center outputs a
digital control signal to the bass module. The older music centers (CD5 and
do not have this function and will not work with the AM-8 series II bass module. The label below shows the V2 designation.
All 3 of the CD-5 versions (CD5, CD5V, CD5V2) look identical, however the insides are very different.
CD5V2 CD5V2 Label
AM-8P series II Bass Module AM-8 label
Note: The AM-8P series II digital bass
module looks the same as earlier analog versions but are NOT interchangeable.
An easy way to tell the difference is to count the number of pins in in the multi-pin connector, 8 pins is the earlier analog version,
13 pins is the newer digital version.
We have parts in stock to repair the bass module,
and all the CD-5 music centers.
We don't have any parts for the satellite cube speakers.
